Security combi window stay AXAflex Security

2660-20-57/CP

+

2
arrow_selector
close

SKG 2

Police Hallmark

The AXAflex Security combi window stay is burglar-resistant and makes it possible to use hopper windows for ventilation purposes.

  • security window stay and closer in one
  • variable with three preferred positions for optimal ventilation
  • lockable and readable via red-and-white indicator
  • maximum ventilation opening 160 mm
  • rotatable
  • complies with the Police Hallmark for Safe Living and SKG2
Specifications Downloads Technical drawings Associated products Alternative products Similar products

Specifications

Recommended Mounting Materials
- 4.5 x 40 mm screw: 8 pieces
Commercial information
expand_more
Type AXAflex Security
Use for skylights, hopper windows and top-hung windows
Safety information
expand_more
Burglarproof True
SKG SKG 2
Police Hallmark True
CE Applicable False
Technical information
expand_more
Product Length 182 mm
Product Width 67 mm
Product Height 54 mm
Direction of rotation turning upwards
Maximum gap width 160 mm
Maximum height vertical position 160 mm
Rotatable to the right
Operation variable with 3 preferred positions for optimal ventilation
Number of Keys 1
Material Stainless steel
Finish Black lacquered
Material 2 Synthetic
Finish 2 Black
Assembly information
expand_more
Including Mounting Material True
Mounting length 182 mm
Required depth wood frame 36 mm
Window/door mounting width requirement 37 mm
Assembly time 20 min
Recommended Mounting Materials
- 4.5 x 40 mm screw: 8 pieces
Logistic information
expand_more
Pieces per small package 1 piece
EAN small package 8713249354705
Weight small package 0.312 kg
Dimensions small package 265 x 85 x 45 mm
Pieces per bulk package 6 piece
EAN bulk package 8713249354712
Weight bulk package 2.06 kg
Dimensions bulk package 275 x 175 x 140 mm

Technical drawings
