Ball bearing hinge ball bearing

1531-96-81
arrow_selector
close

Ball bearing for hinge types 1531, 1533, 1537, 5141, 1543, 1657 and 1667, 89 mm high.

smooth-running
Specifications Downloads Technical drawings

Specifications

Recommended Mounting Materials
- 4.0 x 40 mm screw: 8 pieces
Commercial information
expand_more
Type hinge ball bearing
Use for hinge type 1537, 1547, 1657 and 1667 of 89 mm high
Safety information
expand_more
Burglarproof False
SKG No
Police Hallmark False
CE Applicable False
Technical information
expand_more
Thickness 7 mm
Diameter outside 13 mm
Material Stainless steel
Finish Brushed
Assembly information
expand_more
Including Mounting Material False
Recommended Mounting Materials
- 4.0 x 40 mm screw: 8 pieces
Logistic information
expand_more
Product Weight 3.3 gr
Pieces per small package 100 piece
EAN small package 8713249108902
Weight small package 0.334 kg
Dimensions small package 165 x 140 mm
Pieces per bulk package 2000 piece
EAN bulk package 8713249108919
Weight bulk package 6.87 kg
Dimensions bulk package 290 x 200 x 120 mm

Technical drawings
Ball bearing hinge ball bearing
15319681
