Security hinge Titan
1711-09-56/7V2

The AXA Titan® security hinge is a smooth-running hinge with a high bearing capacity.
- high bearing capacity thanks to special unique double rolling
- 180 kg with 3 hinges
- with patented lockingsystem
- excellent to combine with door control and en doorstops, door extreme high side strength
- very smooth-running, silent and hard-wearing
- the special star-shaped screw holes reduce the chance of screw breakage
- with the Police Hallmark for Safe Living and SKG3



The AXA Titan® security hinge is a smooth-running hinge with a high bearing capacity.
- high bearing capacity thanks to special unique double rolling
- 180 kg with 3 hinges
- with patented lockingsystem
- excellent to combine with door control and en doorstops, door extreme high side strength
- very smooth-running, silent and hard-wearing
- the special star-shaped screw holes reduce the chance of screw breakage
- with the Police Hallmark for Safe Living and SKG3
Specifications
Recommended Mounting Materials
- 4.5 x 45 mm screw: 8 pieces
- 4.5 x 45 mm screw: 8 pieces
Commercial information
Type Titan
Use for windows and exterior doors
Safety information
Burglarproof True
SKG SKG 3
Police Hallmark True
CE Applicable True
Technical information
Product Width 89 mm
Product Height 89 mm
Thickness 2.5 mm
Diameter knuckle 15 mm
Corner shape round corner
Direction of rotation outward-opening
Load bearing capacity 2 hinges 120 kg
Load bearing capacity 3 hinges 180 kg
Material Steel
Finish Black lacquered
Assembly information
Including Mounting Material False
Recommended Mounting Materials
- 4.5 x 45 mm screw: 8 pieces
- 4.5 x 45 mm screw: 8 pieces
Logistic information
Product Weight 278 gr
Pieces per bulk package 25 piece
EAN bulk package 8713249351971
Downloads
Main Image Brochure Installation Manual Declaration of Performance SKG Certificate Environmental Product Declaration (EPD)Technical drawings
