Security hinge Smart Easyfix
1687-12-23/VE
The AXA Smart Easyfix® security hinge is a smooth-running, burglar-resistant hinge with high bearing capacity and hard-wearing plastic bearings.
- security model with built-in security pin
- very smooth-running, silent, hard-wearing and self-lubricating, making black marks on the paintwork a thing of the past
- high bearing capacity thanks to pressure distribution over two points
- with gap limiter
- with special, chamfered, self-aligning AXA-POM bearings. These bearings have a fixation collar that stops them from falling out of the hinge
- the special star-shaped screw holes reduce the chance of screw breakage
- complies with the Police Hallmark for Safe Living and SKG3
The AXA Smart Easyfix® security hinge is a smooth-running, burglar-resistant hinge with high bearing capacity and hard-wearing plastic bearings.
- security model with built-in security pin
- very smooth-running, silent, hard-wearing and self-lubricating, making black marks on the paintwork a thing of the past
- high bearing capacity thanks to pressure distribution over two points
- with gap limiter
- with special, chamfered, self-aligning AXA-POM bearings. These bearings have a fixation collar that stops them from falling out of the hinge
- the special star-shaped screw holes reduce the chance of screw breakage
- complies with the Police Hallmark for Safe Living and SKG3
Specifications
Recommended Mounting Materials
- 4.5 x 40 mm screw: 8 pieces
- 4.5 x 40 mm screw: 8 pieces
Commercial information
Type Smart Easyfix
Use for windows and exterior doors
Safety information
Burglarproof True
SKG SKG 3
Police Hallmark True
CE Applicable True
Technical information
Product Width 125 mm
Product Height 89 mm
Thickness 3 mm
Diameter knuckle 15 mm
Corner shape round corner
Bearing AXApom synthetic bearing
Direction of rotation outward-opening
Security pin size 18 mm
Diameter security pin 10 mm
Load bearing capacity 3 hinges 80 kg
Load bearing capacity 4 hinges 90 kg
Material Steel
Finish Topcoat galvanized
Assembly information
Including Mounting Material False
Recommended Mounting Materials
- 4.5 x 40 mm screw: 8 pieces
- 4.5 x 40 mm screw: 8 pieces
Logistic information
Product Weight 326 gr
Pieces per small package 4 piece
EAN small package 8713249240459
Weight small package 1.35 kg
Dimensions small package 140 x 94 x 57 mm
Pieces per bulk package 16 piece
EAN bulk package 8713249240466
Weight bulk package 5.51 kg
Dimensions bulk package 200 x 150 x 120 mm
